Microchip – PIC16F882-I/SO SOIC
This powerful yet easy-to-program (only 35 single word instructions) CMOS FLASH-based 8-bit microcontroller packs Microchip’s powerful PIC® architecture into a 28 pin package.The PIC16F882 features 128 bytes of EEPROM data memory, self programming, an ICD, 2 Comparators, 11 channels of 10-bit Analog-to-Digital (A/D) converter, 1 capture/compare/PWM and 1 Enhanced capture/compare/PWM functions, a synchronous serial port that can be configured as either 3-wire Serial Peripheral Interface (SPI™) or the 2-wire Inter-Integrated Circuit (I²C™) bus and an Enhanced Universal Asynchronous Receiver Transmitter (EUSART). All of these features make it ideal for more advanced level A/D applications in automotive, industrial, appliances or consumer applications.
DOWNLOADS:
Product Features:
- Special Microcontroller Features: • Precision Internal Oscillator: – Factory calibrated to ±1% – Software selectable frequency range of 8 MHz to 32 kHz – Software tunable – Two-Speed Start-Up mode – Fail-safe clock monitoring for critical applications – Clock mode switching during operation for low-power operation • Power-Saving Sleep mode • Power-on Reset (POR) • Selectable Brown-out Reset (BOR) voltage • Extended Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation • In-Circuit Serial Programming™ (ICSP™) via two pins • In-Circuit Debug (ICD) via two pins • High-endurance Flash/EEPROM cell: – 100,000 erase/write cycle enhanced Flash program memory, typical – 1,000,000 erase/write cycle data EEPROM memory, typical – Data EEPROM retention > 40 years • Self-reprogrammable under software control • Programmable code protection •Peripheral Features: Device Features: – 1 input only pin – 25 I/O – High sink/source current 25 mA – Interrupt-on-pin change option • Timers: – TMR0: 8-bit timer/counter with 8-bit prescaler – TMR1 enhanced: 16-bit timer/counter with prescaler, External Gate Input mode and dedicated low-power 32 kHz oscillator – TMR2: 8-bit timer/counter with 8-bit period register, prescaler and postscaler • Capture/Compare/PWM (CCP) module • Enhanced Capture/Compare/PWM (ECCP) module with auto-shutdown and PWM steering • Master Synchronous Serial Port (MSSP) module SPI™ mode, I2C™ mode with address mask capability • Enhanced Universal Synchronous Asynchronous Receiver Transmitter (EUSART) module: – Supports RS-485, RS-232 and LIN compatibility – Auto-Baud Detect – Auto-wake-up on Start bit • Ultra Low-Power Wake-up (ULPWU) Analog Features: • 10-bit 11 channel Analog-to-Digital (A/D) Converter • 2 Analog Comparator modules with: – Programmable on-chip Voltage Reference (CVREF) module (% of VDD) – Fixed 0.6 Vref – Comparator inputs and outputs externally accessible – SR Latch mode
Related products
Microchip – PIC12F683-I/SN SOIC
Alternate Products: PIC16F18323
The Low Pin-count (8) PIC® Flash microcontroller products offer all of the advantages of the well recognized mid-range x14 architecture with standardized features including a wide operating voltage of 2.0-5.5 volts, on-board EEPROM Data Memory, and nanoWatt Technology. Standard analog peripherals include up to 4 channels of 10-bit A/D, an analog comparator module with a single comparator, programmable on-chip voltage reference and a Standard Capture/Compare/PWM (CCP) module.
DOWNLOADS:
Microchip – PIC16F72-I/SO SOIC
This powerful (200 nanosecond instruction execution) yet easy-to-program (only 35 single word instructions) CMOS FLASH-based 8-bit microcontroller packs Microchip's powerful PIC® architecture into an 28-pin package and is upwards compatible with the PIC16C5X, PIC12CXXX and PIC16C7X devices. The PIC16F72 features 5 channels of 8-bit Analog-to-Digital (A/D) converter with 2 additional timers, capture/compare/PWM function and the synchronous serial port can be configured as either 3-wire Serial Peripheral Interface (SPI™) or the 2-wire Inter-Integrated Circuit (I²C™) bus. All of these features make it ideal for more advanced level A/D applications in automotive, industrial, appliances and consumer applications.
DOWNLOADS:
Microchip – PIC16F876A-I/SO SOIC
Alternate Products: PIC16F886
A newer device is available. Please consider the PIC16F886. This powerful (200 nanosecond instruction execution) yet easy-to-program (only 35 single word instructions) CMOS FLASH-based 8-bit microcontroller packs Microchip's powerful PIC® architecture into an 28-pin package and is upwards compatible with the PIC16C5X, PIC12CXXX and PIC16C7X devices. PIC16F876 features 256 bytes of EEPROM data memory, self programming, an ICD, 5 channels of 10-bit Analog-to-Digital (A/D) converter, 2 additional timers, 2 capture/compare/PWM functions, the synchronous serial port can be configured as either 3-wire Serial Peripheral Interface (SPI™) or the 2-wire Inter-Integrated Circuit (I²C™) bus and a Universal Asynchronous Receiver Transmitter (USART). All of these features make it ideal for more advanced level A/D applications in automotive, industrial, appliances and consumer applications.
DOWNLOADS:
Microchip – PIC16F883-I/SO SOIC
This powerful yet easy-to-program (only 35 single word instructions) CMOS FLASH-based 8-bit microcontroller packs Microchip's powerful PIC® architecture into a 28 pin package.The PIC16F883 features 256 bytes of EEPROM data memory, self programming, an ICD, 2 Comparators, 11 channels of 10-bit Analog-to-Digital (A/D) converter, 1 capture/compare/PWM and 1 Enhanced capture/compare/PWM functions, a synchronous serial port that can be configured as either 3-wire Serial Peripheral Interface (SPI™) or the 2-wire Inter-Integrated Circuit (I²C™) bus and an Enhanced Universal Asynchronous Receiver Transmitter (EUSART). All of these features make it ideal for more advanced level A/D applications in automotive, industrial, appliances or consumer applications.
DOWNLOADS:
- Data Sheet
Microchip – PIC16F887-I/PT TQFP
This powerful yet easy-to-program (only 35 single word instructions) CMOS FLASH-based 8-bit microcontroller packs Microchip's powerful PIC® architecture into an 40- or 44-pin package.The PIC16F887 features 256 bytes of EEPROM data memory, self programming, an ICD, 2 Comparators, 14 channels of 10-bit Analog-to-Digital (A/D) converter, 1 capture/compare/PWM and 1 Enhanced capture/compare/PWM functions, a synchronous serial port that can be configured as either 3-wire Serial Peripheral Interface (SPI™) or the 2-wire Inter-Integrated Circuit (I²C™) bus and an Enhanced Universal Asynchronous Receiver Transmitter (EUSART). All of these features make it ideal for more advanced level A/D applications in automotive, industrial, appliances or consumer applications.
DOWNLOADS:
