Microchip – PIC18F46J11-I/PT TQFP
This family provides low power and high performance 8-bit MCU with peripheral flexibility in a small package for cost sensitive applications in the PIC18 J-series. New features include Deep sleep mode for low power applications, Peripheral Pin Select for design flexibility for mapping peripherals to I/O pins and a CTMU module for easy capacitive touch user interfaces. The PIC18F46J11 family is ideal for applications requiring cost-effective, low-power solutions with a robust peripheral set in a small package.
DOWNLOADS:
Product Features:
- 13nA Deep Sleep mode (Watch Webinar)
- 54nA Sleep mode (RAM retention)
- 830nA Real Time Clock & Calendar operation in Sleep modes
- 820nA Watch Dog Timer operation in Sleep modes
- Deep Sleep mode ideal for battery applications
- Peripheral Pin Select for mapping digital peripherals to various I/O for design flexibility
- Hardware RTCC provides clock, calendar & alarm functions
- Charge Time Measurement Unit (CTMU) supports capacitive touch screens
- 2 Enhanced Capture / Compare / PWM modules
- 2 MSSP serial ports for SPI or I2C™ communication
- 2 Enhanced USART modules
- 8-bit Parallel port
- Dual analog comparators
- 13 ch, 10-bit ADC
- Self programming Flash supports 10k erase/write cycles & 20 years retention
- Operating voltage 2.0 – 3.6V, 5.5V tolerant digital inputs
