Mechanical DataÂ
Case : JEDEC ABS molded plastic body
Terminals : Solderable per MIL-STD-750,Method 2026
Polarity : Polarity symbol marking on body Mounting
Position: Any
Weight : 0.0031 ounce, 0.088 grams
MDD-ABS210
Features
- Glass Passivated Chip Junction
- Reverse Voltage – 100 to 1000 V
- Forward Current- 2.0 A
- Fast reverse recovery time
- Designed for Surface Mount Application
